DDR3L X16 4Gb DRAM Chip Industrial F60C1A0004-M7 F60C1A0004-M79W

I'm Online Chat Now

DDR3L X16 4Gb DRAM Chip Industrial F60C1A0004-M7 F60C1A0004-M79W

DDR3L X16 4Gb DRAM Chip Industrial F60C1A0004-M7 F60C1A0004-M79W
DDR3L X16 4Gb DRAM Chip Industrial F60C1A0004-M7 F60C1A0004-M79W DDR3L X16 4Gb DRAM Chip Industrial F60C1A0004-M7 F60C1A0004-M79W DDR3L X16 4Gb DRAM Chip Industrial F60C1A0004-M7 F60C1A0004-M79W

Large Image :  DDR3L X16 4Gb DRAM Chip Industrial F60C1A0004-M7 F60C1A0004-M79W

Product Details:
Place of Origin: CN
Brand Name: FORESEE
Certification: ROHS
Model Number: F60C1A0004-M79W
Document: B77B7C8B45209AC07A2589ABAA9...C1.pdf
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: consult with
Packaging Details: T/R
Delivery Time: 5-8day
Payment Terms: Western Union,T/T
Supply Ability: 10000
Contact Now Chat Now

DDR3L X16 4Gb DRAM Chip Industrial F60C1A0004-M7 F60C1A0004-M79W

Description
Product Catalogue: Memory > Dynamic Random Access Memory (DRAM) Universal Packaging: FBGA-96
RoHS: Compliance Installation Method: Surface Mount Installation
Operating Temperature: - Length * Width * Height: -
Application Grade: Industrial Grade Minimum Working Power Supply Voltage: 1.35V
Highlight:

DDR3L X16 dram chip

,

4Gb dram chip

,

F60C1A0004-M79W

Dynamic Random Access Memory DRAM Industrial F60C1A0004-M7 DDR3L X16 4Gb F60C1A0004-M79W
Product Specifications
Attribute Value
Product Catalogue Memory > Dynamic Random Access Memory (DRAM)
Universal packaging FBGA-96
RoHS Compliance
Installation method Surface mount installation
Application grade Industrial grade
Minimum working power supply voltage 1.35V
Storage capacity 512MB
Maximum working power supply voltage 1.5V
Device Features
  • Density: 4G bits (256Meg x 16 bits)
  • Package: 96-ball FBGA (Lead-free and Halogen-free)
  • Power supply: VDD/VDDQ = 1.35V (1.283 to 1.45V)
  • Backward compatible DDR3 (1.5V) operation
  • Data Rate: 1600Mbps, 1866Mbps
  • 2KB page size (x16)
  • Eight internal banks for concurrent operation
  • CAS Latency (CL): 5-14
  • CAS Write Latency (CWL): 5-10
  • Operating temperature range: -40°C to +95°C (Industrial)
  • Double data-rate architecture: two data transfers per clock cycle
  • On-Die Termination (ODT) for better signal quality
  • JEDEC compliant DDR3 RH-Free (Row Hammer Free) option available
Product Images
Packaging and Transportation

According to the standard export packaging. Customers can choose from cartons, wooden cases and wooden pallets according to their own requirements.

Frequently Asked Questions
1. How to obtain the price?

We usually quote within 24 hours after receiving your inquiry (except weekends and holidays). If you are in urgent need of a price, please send us an email or contact us in any other way so that we can provide you with a quotation.

2. What is your delivery time?

This depends on the quantity of the order and the season in which you place the order. Usually, we can ship the goods within 7 to 15 days (for small batches), and for large batches, it takes about 30 days.

3. What are your payment terms?

Factory price, 30% deposit, 70%T/T payment before shipment.

4. What is the mode of transportation?

It can be transported by sea, air or express delivery (EMS, UPS, DHL, TNT, FEDEX, etc.). Please confirm with us before placing an order.

5. How do you help our business establish a long-term and good relationship?

We maintain good quality and competitive prices to ensure that our customers benefit. We respect every customer as our friend and do business with them sincerely.
