CESD12VD5 Uni-direction ESD Protection Diode Unidirectional ESD Protection Device With 12V Reverse Cut-off Voltage

CESD12VD5 Uni-direction ESD Protection Diode Unidirectional ESD Protection Device With 12V Reverse Cut-off Voltage
CESD12VD5 Uni-direction ESD Protection Diode Unidirectional ESD Protection Device With 12V Reverse Cut-off Voltage CESD12VD5 Uni-direction ESD Protection Diode Unidirectional ESD Protection Device With 12V Reverse Cut-off Voltage CESD12VD5 Uni-direction ESD Protection Diode Unidirectional ESD Protection Device With 12V Reverse Cut-off Voltage CESD12VD5 Uni-direction ESD Protection Diode Unidirectional ESD Protection Device With 12V Reverse Cut-off Voltage

Large Image :  CESD12VD5 Uni-direction ESD Protection Diode Unidirectional ESD Protection Device With 12V Reverse Cut-off Voltage

Product Details:
Place of Origin: CN
Brand Name: CJ
Certification: ROHS
Model Number: CESD12VD5
Document: C189685_785ED45E908CBF81396...C1.pdf
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: consult with
Packaging Details: T/R
Delivery Time: 5-8day
Payment Terms: T/T,Western Union
Supply Ability: 100000
Contact Now Chat Now

CESD12VD5 Uni-direction ESD Protection Diode Unidirectional ESD Protection Device With 12V Reverse Cut-off Voltage

Description
Reverse Cut-off Voltage (Vrwm): 12V Clamping Voltage: 24V
Peak PulsePower (Ppp): 9A@8/20us Operating Temperature: -
Protection Level: IEC 61000-4-2 C-Junction Capacitance: 45pF
Highlight:

Panasonic CR2450 lithium coin battery

,

3V lithium coin battery 620mAh

,

24mm lithium ion battery

CESD12VD5 Uni-direction ESD Protection Diode Unidirectional ESD Protection Device With 12V Reverse Cut-off Voltage

Features
  • Uni-directional ESD protection of one line
  • Reverse stand−off voltage: 12V
  • Low reverse clamping voltage
  • Low leakage current
  • Excellent package:1.20mm×0.80mm×0.60mm
  • Fast response time
  • JESD22-A114-B ESD Rating of class 3B per humanbody model
  • IEC 61000-4-2 Level 4 ESD protection
Applications
  • Computers and peripherals
  • Digital Cameras
  • Audio and video equipment
  • Cellular handsets and accessories
  • Portable electronics
  • Mp3 Players
  • Other electronics equipments communication systems
Technical Parameters
Parameter Symbol Test conditions Min Typ Max Unit
Reverse stand off voltage VRWM(1)


12 V
Reverse leakage current IR VRWM=12V

1 μA
Breakdown voltage V(BR) IT=1mA 14.1
16.5 V
Clamping voltage VC(2) IPP=9 A

24 V
Forward voltage VF IF=10mA

0.9 V
Junction capacitance CJ VR=0V,f=1MHz

45 pF

CESD12VD5 Uni-direction ESD Protection Diode Unidirectional ESD Protection Device With 12V Reverse Cut-off Voltage 0

CESD12VD5 Uni-direction ESD Protection Diode Unidirectional ESD Protection Device With 12V Reverse Cut-off Voltage 1CESD12VD5 Uni-direction ESD Protection Diode Unidirectional ESD Protection Device With 12V Reverse Cut-off Voltage 2

Packaging & Shipping

Standard export packaging available. Customers can choose from cartons, wooden cases, and wooden pallets according to their requirements.

Frequently Asked Questions

How to obtain the price?

We typically provide quotations within 24 hours of receiving your inquiry (excluding weekends and holidays). For urgent pricing requests, please contact us directly.

What is your delivery time?

Small batches typically ship within 7-15 days, while large batch orders may require approximately 30 days depending on order quantity and season.

What are your payment terms?

Factory pricing with 30% deposit and 70% balance payment via T/T before shipment.

What are the shipping options?

Available shipping methods include sea freight, air freight, and express delivery (EMS, UPS, DHL, TNT, FEDEX). Please confirm your preferred method before ordering.
