AMS1117-3.3 3.3V 1A 16V Linear Voltage Regulator LDO for High Efficiency Power Management

Large Image : AMS1117-3.3 3.3V 1A 16V Linear Voltage Regulator LDO for High Efficiency Power Management

Product Details:

Place of Origin:	CN
Brand Name:	AMS
Certification:	rohs
Model Number:	AMS1117-3.3
Document:	C6186_7A095716F0823C02F1997...1).pdf

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	consult with
Packaging Details:	T/R
Delivery Time:	5-8days
Payment Terms:	T/T,Western Union
Supply Ability:	100000

Contact Now Chat Now

AMS1117-3.3 3.3V 1A 16V Linear Voltage Regulator LDO for High Efficiency Power Management

Description

Product Catalogue:	Linear Voltage Regulator (LDO)	Working Voltage:	16V
Output Voltage:	3.3V	Output Current:	1A
Power Supply Rejection Ratio (PSRR):	72dB@(120Hz)	Pressure Difference:	1.1V@(800mA)
Highlight:	3.3V Output Linear Voltage Regulator , 1A Output Current LDO , 16V Working Voltage Voltage Regulator IC

AMS1117-3.3 3.3V 1A 16V Linear Voltage Regulator (LDO)

FEATURES

Three Terminal Adjustable or Fixed Voltages* 1.5V, 1.8V, 2.5V, 2.85V, 3.3V and 5.0V
Output Current of 1A
Operates Down to 1V Dropout
Line Regulation: 0.2% Max.
Load Regulation: 0.4% Max.
SOT-223, TO-252 and SO-8 package available

APPLICATIONS

High Efficiency Linear Regulators
Post Regulators for Switching Supplies
5V to 3.3V Linear Regulator
Battery Chargers
Active SCSI Terminators
Power Management for Notebook
Battery Powered Instrumentation

PACKAGE TYPE & OPERATING JUNCTION TEMPERATURE RANGE

TO-252	SOT-223	8L SOIC	OPERATING JUNCTION TEMPERATURE RANGE
AMS1117CD	AMS1117	AMS1117CS	-40 to 125° C
AMS1117CD-1.5	AMS1117-1.5	AMS1117CS-1.5	-40 to 125° C
AMS1117CD-1.8	AMS1117-1.8	AMS1117CS-1.8	-40 to 125° C
AMS1117CD-2.5	AMS1117-2.5	AMS1117CS-2.5	-40 to 125° C
AMS1117CD-2.85	AMS1117-2.85	AMS1117CS-2.85	-40 to 125° C
AMS1117CD-3.3	AMS1117-3.3	AMS1117CS-3.3	-40 to 125° C
AMS1117CD-5.0	AMS1117-5.0	AMS1117CS-5.0	-40 to 125° C

AMS1117-3.3 3.3V 1A 16V Linear Voltage Regulator LDO for High Efficiency Power Management 0

Packaging & Shipping

Standard export packaging available. Customers can choose from cartons, wooden cases, and wooden pallets according to their requirements.

Frequently Asked Questions

How to obtain the price?

We typically provide quotations within 24 hours of receiving your inquiry (excluding weekends and holidays). For urgent pricing requests, please contact us directly.

What is your delivery time?

Small batches typically ship within 7-15 days, while large batch orders may require approximately 30 days depending on order quantity and season.

What are your payment terms?

Factory pricing with 30% deposit and 70% balance payment via T/T before shipment.

What are the shipping options?

Available shipping methods include sea freight, air freight, and express delivery (EMS, UPS, DHL, TNT, FEDEX). Please confirm your preferred method before ordering.
