GD25Q80CTIGR NOR FLASH 3.3V Uniform SectorDual and Quad Serial Flash 600us SPI

GD25Q80CTIGR NOR FLASH 3.3V Uniform SectorDual and Quad Serial Flash 600us SPI
GD25Q80CTIGR NOR FLASH 3.3V Uniform SectorDual and Quad Serial Flash 600us SPI GD25Q80CTIGR NOR FLASH 3.3V Uniform SectorDual and Quad Serial Flash 600us SPI GD25Q80CTIGR NOR FLASH 3.3V Uniform SectorDual and Quad Serial Flash 600us SPI GD25Q80CTIGR NOR FLASH 3.3V Uniform SectorDual and Quad Serial Flash 600us SPI

Large Image :  GD25Q80CTIGR NOR FLASH 3.3V Uniform SectorDual and Quad Serial Flash 600us SPI

Product Details:
Place of Origin: CN
Brand Name: GigaDevice
Certification: rohs
Model Number: GD25Q80CTIGR
Document: C395525_DB408F20F1FE0C0515D...5B.pdf
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: consult with
Packaging Details: T/R
Delivery Time: 5-8days
Payment Terms: T/T,Western Union
Supply Ability: 100000
Contact Now Chat Now

GD25Q80CTIGR NOR FLASH 3.3V Uniform SectorDual and Quad Serial Flash 600us SPI

Description
Operating Temperature: -40℃~+85℃ Operating Voltage: 2.7V~3.6V
Interface Type: SPI Storage Capadity: 8Mbit
Clock Frequency (fc): 120MHz Page Write Time (Tpp): 600us
Highlight:

3.3V NOR FLASH memory

,

SPI NOR FLASH with warranty

,

Quad Serial Flash 600us

GD25Q80CTIGR NOR FLASH 3.3V Uniform Sector Dual and Quad Serial Flash
The GD25Q80CTIGR is an 8M-bit Serial Flash memory featuring 3.3V operation with uniform sector architecture. This high-performance device supports Standard, Dual, and Quad SPI interfaces with fast 600μs programming capabilities.
Key Features
  • 8M-bit Capacity: 1024K-Byte memory with 256 bytes per programmable page
  • Fast Program/Erase Speed:
    • Page Program time: 0.6ms typical
    • Sector Erase time: 45ms typical
    • Block Erase time: 0.15/0.25s typical
    • Chip Erase time: 4s typical
  • Multiple SPI Interfaces:
    • Standard SPI: SCLK, CS#, SI, SO, WP#, HOLD#
    • Dual SPI: SCLK, CS#, IO0, IO1, WP#, HOLD#
    • Quad SPI: SCLK, CS#, IO0, IO1, IO2, IO3
  • Flexible Architecture: Uniform Sector of 4K-Byte and Uniform Block of 32/64K-Byte
  • High Speed Performance:
    • 120MHz fast read with 30PF load
    • Dual I/O Data transfer up to 240Mbits/s
    • Quad I/O Data transfer up to 480Mbits/s
  • Low Power Consumption: 1μA typical deep power down and standby current
  • Write Protection: Software/hardware write protection with WP# Pin and Top/Bottom Block Protection
  • Advanced Security: 128-Bit Unique ID, 4x256-Byte security registers with OTP locks, and SFDP register
Memory Architecture
Each device has Each block has Each sector has Each page has
1M 64/32K 4K 256 Bytes
4K 256/128 16 - pages
256 16/8 - - sectors
16/32 - - - blocks
Product Images
GD25Q80CTIGR NOR FLASH 3.3V Uniform SectorDual and Quad Serial Flash 600us SPI 0 GD25Q80CTIGR NOR FLASH 3.3V Uniform SectorDual and Quad Serial Flash 600us SPI 1 GD25Q80CTIGR NOR FLASH 3.3V Uniform SectorDual and Quad Serial Flash 600us SPI 2 GD25Q80CTIGR NOR FLASH 3.3V Uniform SectorDual and Quad Serial Flash 600us SPI 3
Packaging & Shipping
Standard export packaging available. Customers can choose from cartons, wooden cases, and wooden pallets according to their specific requirements.
Frequently Asked Questions
How to obtain the price?
We typically provide quotations within 24 hours of receiving your inquiry (excluding weekends and holidays). For urgent pricing requests, please contact us directly.
What is your delivery time?
Small batches typically ship within 7-15 days, while large batch orders may require approximately 30 days depending on order quantity and season.
What are your payment terms?
Factory pricing with 30% deposit and 70% balance payment via T/T before shipment.
What are the shipping options?
Available shipping methods include sea freight, air freight, and express delivery (EMS, UPS, DHL, TNT, FEDEX). Please confirm your preferred method before ordering.
