STM32F407VET6 ARM Cortex-M4 32b MCU+FPU, 210DMIPS Up To 1MB Flash/192+4KB RAM USBOTG HS/FS Ethernet 17 TIMs 3 ADCs 15 Comm Interfaces & Camera

STM32F407VET6 ARM Cortex-M4 32b MCU+FPU, 210DMIPS Up To 1MB Flash/192+4KB RAM USBOTG HS/FS Ethernet 17 TIMs 3 ADCs 15 Comm Interfaces & Camera
STM32F407VET6 ARM Cortex-M4 32b MCU+FPU, 210DMIPS Up To 1MB Flash/192+4KB RAM USBOTG HS/FS Ethernet 17 TIMs 3 ADCs 15 Comm Interfaces & Camera STM32F407VET6 ARM Cortex-M4 32b MCU+FPU, 210DMIPS Up To 1MB Flash/192+4KB RAM USBOTG HS/FS Ethernet 17 TIMs 3 ADCs 15 Comm Interfaces & Camera STM32F407VET6 ARM Cortex-M4 32b MCU+FPU, 210DMIPS Up To 1MB Flash/192+4KB RAM USBOTG HS/FS Ethernet 17 TIMs 3 ADCs 15 Comm Interfaces & Camera

Large Image :  STM32F407VET6 ARM Cortex-M4 32b MCU+FPU, 210DMIPS Up To 1MB Flash/192+4KB RAM USBOTG HS/FS Ethernet 17 TIMs 3 ADCs 15 Comm Interfaces & Camera

Product Details:
Place of Origin: CN
Brand Name: ST
Certification: rohs
Model Number: STM32F407VET6
Document: 1457707197138 (2).pdf
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: consult with
Packaging Details: T/R
Delivery Time: 5-8days
Payment Terms: T/T,Western Union
Supply Ability: 100000
Contact Now Chat Now

STM32F407VET6 ARM Cortex-M4 32b MCU+FPU, 210DMIPS Up To 1MB Flash/192+4KB RAM USBOTG HS/FS Ethernet 17 TIMs 3 ADCs 15 Comm Interfaces & Camera

Description
Product Category:: MCU Maximum Clock Frequency:: 168MHz
Data Bus Width:: 32 Bit Program Memory Size:: 512KB
Program Memory Type:: FLASH Data RAM Size:: 192KB
Number Of I/Os:: 82
Highlight:

STM32F407VET6 Cortex-M4 microcontroller

,

32-bit MCU with 1MB Flash

,

ARM microcontroller with USB OTG

STM32F407VET6 ARM Cortex-M4 32-bit MCU with FPU
High-performance 32-bit microcontroller featuring ARM Cortex-M4 core with FPU, delivering 210 DMIPS with up to 1MB Flash memory and 192+4KB RAM. Includes USB OTG HS/FS, Ethernet, 17 timers, 3 ADCs, 15 communication interfaces, and camera interface.
Key Features
  • Core: ARM 32-bit Cortex-M4 CPU with FPU, Adaptive real-time accelerator (ART Accelerator) for 0-wait state execution from Flash memory
  • Frequency: Up to 168 MHz with 210 DMIPS/1.25 DMIPS/MHz (Dhrystone 2.1) and DSP instructions
  • Memory Protection Unit for enhanced security
Memory Configuration
  • Up to 1 MB of Flash memory
  • Up to 192+4 KB of SRAM including 64-KB CCM (core coupled memory) data RAM
  • Flexible static memory controller supporting Compact Flash, SRAM, PSRAM, NOR and NAND memories
  • LCD parallel interface with 8080/6800 modes
Clock, Reset and Power Management
  • 1.8 V to 3.6 V application supply and I/Os
  • POR, PDR, PVD and BOR protection
  • 4-to-26 MHz crystal oscillator
  • Internal 16 MHz factory-trimmed RC (1% accuracy)
  • 32 kHz oscillator for RTC with calibration
  • Internal 32 kHz RC with calibration
Low Power Operation
  • Sleep, Stop and Standby modes
  • VBAT supply for RTC
  • 20×32 bit backup registers + optional 4 KB backup SRAM
Analog and Digital Conversion
  • 3×12-bit, 2.4 MSPS A/D converters: up to 24 channels and 7.2 MSPS in triple interleaved mode
  • 2×12-bit D/A converters
DMA and Timer Systems
  • General-purpose DMA: 16-stream DMA controller with FIFOs and burst support
  • Up to 17 timers: up to twelve 16-bit and two 32-bit timers up to 168 MHz
  • Each timer supports up to 4 IC/OC/PWM or pulse counter and quadrature (incremental) encoder input
Product References
Reference Part Numbers
STM32F405xx STM32F405RG, STM32F405VG, STM32F405ZG, STM32F405OG, STM32F405OE
STM32F407xx STM32F407VG, STM32F407IG, STM32F407ZG, STM32F407VE, STM32F407ZE, STM32F407IE
STM32F407VET6 ARM Cortex-M4 32b MCU+FPU, 210DMIPS Up To 1MB Flash/192+4KB RAM USBOTG HS/FS Ethernet 17 TIMs 3 ADCs 15 Comm Interfaces & Camera 0 STM32F407VET6 ARM Cortex-M4 32b MCU+FPU, 210DMIPS Up To 1MB Flash/192+4KB RAM USBOTG HS/FS Ethernet 17 TIMs 3 ADCs 15 Comm Interfaces & Camera 1 STM32F407VET6 ARM Cortex-M4 32b MCU+FPU, 210DMIPS Up To 1MB Flash/192+4KB RAM USBOTG HS/FS Ethernet 17 TIMs 3 ADCs 15 Comm Interfaces & Camera 2
Packaging & Shipping
Standard export packaging available. Customers can choose from cartons, wooden cases, and wooden pallets according to their requirements.
Frequently Asked Questions
How to obtain the price?
We typically provide quotations within 24 hours of receiving your inquiry (excluding weekends and holidays). For urgent pricing requests, please contact us directly.
What is your delivery time?
Small batches typically ship within 7-15 days, while large batch orders may require approximately 30 days depending on order quantity and season.
What are your payment terms?
Factory pricing with 30% deposit and 70% balance payment via T/T before shipment.
What are the shipping options?
Available shipping methods include sea freight, air freight, and express delivery (EMS, UPS, DHL, TNT, FEDEX). Please confirm your preferred method before ordering.
